Our product window­sizes

Precise and plannable dimensions for your components

So everything fits

We always want to process your components perfectly, so we need the dimensions and geometries in advance. Please let us know your product sizes in advance, preferably with a dimensioned drawing.

If required, we can also realise larger dimensions. And for customised products and smaller quantities, we do the work ourselves.

Product window sizes

Anodising aluminium and titanium

Anodising
Hard anodising
Eloxieren
Harteloxieren
Procedure / ProcessingLength in mmWidth in mmDepth in mm

Chromic acid and hard and sulphuric acid anodising, yellow and transparent chromating, chromium (VI) free chromating
4600
420
1300

Sulphuric acid and hard anodising, various colours
2600
300
1000

Chemical nickel plating

Chemical nickel plating
Chemical nickel plating
Procedure / ProcessingLength in mmWidth in mmDepth in mm

Chemical nickel plating of steel
1010
320
725

Chemical nickel plating of brass and stainless steel
1010
320
725

Chemical nickel plating of aluminium
1010
320
725

Passivation and passivation of stainless steels

Passivation
Passivation
Procedure / ProcessingLength in mmWidth in mmDepth in mm

80-T-35-1200 Supplement 2
760
220
700

AMS 2700 Typ 2
LAT – 4 – 1201Typ A
DIN-EN-2516 C 1
DIN-EN-2516 C 4
760
220
700

AMS 2700 Typ 8
970
270
700

AMS 2700 Typ 7
760
220
700

80 – T – 35 – 1200 Supplement 1
LAT-4-1201Typ B
2600
440
1000

AMS 2700 Typ 1
2000
310
1000

DIN EN 2516 C 2
2600
440
1000

Mechanical polishing / brushing / sanding / polishingn

Procedure / Processing

On request

Special procedure

Procedure / ProcessingLength in mmWidth in mmDepth in mm

Unlighters from Titan
950
440
750

Pipe cleaning
4500
500
780

a.A. = on request
